The Importance of First Impressions: How Theatre Criticism Might Inform Peer Code Review

Discussion Plays

I have seen plays that have very clear stories, and very clear plots.  I leave the theatre knowing what has happened, and I can be pretty confident that the people who sat around me in the theatre all got the same message as I did.

I have also seen plays that are completely the opposite.  There doesn’t appear to be a story.  There doesn’t appear to be plot.  There are no real characters.  For these plays, all of a sudden, I have to do the work in order to make sense of it all.  And you can be pretty sure that every single audience member got something different out of it.

I want to talk about this second kind of play.  For now, I’m going to call this kind of play a discussion play, because for me, the best part about these kinds of plays is the discussion I have with my friends afterwards. We’ll all sit down in a restaurant or a cafe, order some food, and try to figure out what the hell we just saw.  Theories are tossed around.  Everybody brings their own unique impressions and observations to the table.  A very rich ecosystem of ideas develops.

Back to Peer Code Reviews

(trust me, this all ties together in the end)

When Jason Cohen did his Peer Review at Cisco Study, he noticed that code that had been prepared by the author for review seemed to have a lower defect density than code that had not been prepared.

What do I mean by prepared?  I’ll let Jason Cohen explain:

The idea of “author preparation” is that authors should annotate their source code before the review begins.  Annotations guide the reviewer through the changes, showing which files to look at first and defending the reason and methods behind each code modification.  The theory is that because the author has to re-think all the changes during the annotation process, the author will himself uncover most of the defects before the review even begins, thus making the review itself more efficient.  Reviewers will uncover problems the author truly would not have thought of otherwise.

(Best Kept Secrets of Peer Code Review, p80-81)

Looking at the data, author preparation does seem to have a palpable effect.  As Cohen notes, “for all reviews with at least one author preparation comment, defects density is never over 30; in fact the most common case is for there to be no defects at all!”.

The study has two explanations for this:

  1. Authors gave their code such a thorough look while annotating them, that most defects were eliminated right off the bat.
  2. Since authors were actively explaining, or defending their code, this sabotaged the reviewers ability to do their job effectively.

Cohen buys into the first explanation.  He writes:

A survey of the reviews in question show the author is being conscientious, careful, and helpful, and not misleading the reviewer.  Often the reviewer will respond to or ask a question or open a conversation on another line of code, demonstrating that he was not dulled by the author’s annotations.

I have huge respect for this study.  But I don’t entirely buy this explanation.  As Cohen later mentioned in an email to me, this conclusion is not derived from a controlled experiment, and also suffers from selection bias.

Back to those Discussion Plays

One of the worst things that can happen to me before going into a discussion play is for someone who has already seen it to tell me their impressions of what they thought was going on.  As soon as I hear their opinion, my own objectivity is compromised.  Whether I want to or not, I’ll have their impressions in the back of my mind, and I’ll be using it as a measuring stick or reference point for my own opinions and critiques. They’ve carved a cognitive path through the work, and I’m doomed to notice that path, and react to it.

This is horrible.  This limits me.  This more or less hobbles my ability to contribute something unique to the pool of ideas and criticisms in the after-play discussion.  Every impression I have is tainted by someone else’s first impression.

Don’t get me wrong – I love hearing about everyone’s impressions.  But after I have formed my own. This way, I believe we cover more ground.  A group of us watching a discussion play will carve unique cognitive paths through the work without influencing one another.  When we finally open up and present these paths and ideas to one another over food and drink, I believe we cover more ground.

I have no data to back this up.  Only years of theatre-going experience.

A Code Review Anecdote

I recently received an email from a colleague of mine.  She wanted me to go over some of her Javascript to make sure it was up to snuff, since she was relatively new to the language.  I noticed that she had also sent a copy of the email to another developer who has pretty sharp Javascript chops.

When I finally had some free time, I went back to her email to write up the review.  I felt bad – it was late, and the other reviewer hadn’t made a peep on the email thread, and she was hoping to use the code relatively soon.  So I dove in, wrote my review, and sent it off.

A little while later, the other developer sent me his review, saying:

And here was my answer, which I didn’t send to you so as not to influence your reply.  😉

So the author of the code received two unique reviews, and neither of them had influenced the other.  When I read his review, I noticed that we covered some similar ground, but a lot of unique ground as well.  I suspect this wouldn’t have been the case had he sent his review to me first.

The Hypothesis

I hypothesize that author preparation in code review sabotages reviewers abilities to objectively carve their own unique cognitive paths through the code.  They see things from the author’s point of view, and this dulls their critical eye.  Because of this, I believe fewer defects are detected.

I will take this hypothesis one step further.

I suspect any review, by the author or otherwise, will taint future reviews.  If someone has already reviewed some code, I suspect this review will impact and possibly limit the ability of other reviewers to look at the code objectively.  Like author preparation, I suspect this prevents reviewers from getting their own unique, valuable first impressions of the code.  And I suspect that this causes some defects to go undetected.

Testing This Hypothesis

It’s a simple idea really.  Take a chunk of code, and get some number of developers to review it.  Take this same code, add some author preparation comments, and get more developers to review it.  Do all of the normal balancing, etc.

The question:  do the number of detected defects drop?  If so, this looks like evidence that author preparation sabotages review ability.

Take the experiment one step further.  Take some code, have someone else review it, and then have participants review this code, having seen the first review.  What happens to the number and type of defects that they find?  What happens if they don’t see that initial review?  What yields high defect detection?

Sounds doable.  Sounds interesting.  Sounds like something that would answer a few questions.

Implications and Ideas

So what if one or both of my hypotheses are true?  What does this mean for peer code review?

Well, if author preparation alone sabotages review ability, then the answer is simple:  don’t let the authors prepare the review.  The code goes up, and they stay silent.

But what if both are true?

An idea:  how about I tweak MarkUs’s ReviewBoard so that reviewers cannot see what other reviewers have said until they’ve given one review?  What would happen to the defect detection numbers?  Would reviewers react negatively to this?  Would there be lots of repetition in the comments?  Sounds like something worth looking into.

I’d love to hear some thoughts on this.  Anyone?

Smart Bear, Cisco, and the Largest Study on Code Review Ever

In 2006, Smart Bear software teamed up with the MeetingPlace development group at Cisco Systems, and over 10 months, produced the “largest-ever case study of its kind” on a “light-weight code review process”.

The results of the study can be found in the free book “Best Kept Secrets of Peer Code Review”.

They can also be found in one of the sample chapters that they’ve put on the site.  You can read the study right here, if you’re interested.

Here are my thoughts on the chapter…

First of all, my guard is up a bit. This all seems a bit like a sales pitch, since the software that Cisco ends up using is Smart Bear’s own Code Collaborator. I’m reading the first paragraph, and already I know how it ends – “everybody is happy, the software is improved dramatically, so you should buy Code Collaborator”. Something like that. I’ll be happy when I see some solid data, some numbers, some graphs…

Ok, I’m in at page 54 – they’re talking about how data was collected, and how they pared it down to get the most meaningful results.  This is good.  This sounds like science, and not a sales pitch.  Nice.

The next thing the study talks about is the rate that lines of code (LOC) are analyzed at – the LOC inspection rate.  The data they’ve collected shows no discernible 1-1 correlation between the LOC inspection rate, and the amount of code to inspect.  There were rare exceptions where a reviewer would seem to have such a correlation, but these reviewers tended to be novices who had not participated in many reviews before.  Analyzing the LOC inspection rates by code authors (those who are having their code reviewed) also failed to show any correlations.  In fact, there were several cases where separate reviewers took widely varied amounts of time on the same chunk of code under review.

So this leaves us with no clear answer on what factors play a part in LOC inspection rate.

The study then begins to discuss the effectiveness of the reviews, and whether or not slow reviews reveal more “defects” (where a defect is defined as any change to the code that wouldn’t have happened without the review). Because defect data from the Code Collaborator database was not considered wholly reliable (see pages 62 and 63 if you want to know why), 300 reviews were randomly plucked from the original 2500, and the discussions in each one were analyzed to gather the defect statistics.

The study then introduces the concept of “defect density”, which is a ratio of the number of defects detected per 1000 lines of code (referred to henceforth as kLOC).

I’ll skip right to some results:

Our reviews had an average 32 defects per 1000 lines of code.  61% of the reviews uncovered no defects; of the others the defect density ranged evenly between 10 and 130 defects per kLOC.

I’m surprised that 61% of the reviews found no defects.  That’s remarkably high, in my opinion.  True, it’s only a sample of 300 reviews, but still, my instincts were expecting a significantly lower number.

An even more interesting result, is that defects found (and therefore, review effectiveness) dropped off for large amounts of code to review.  The study notes that:

Anything below 200 lines produces a relatively high rate of defects, often several times the average.

So there seems to be a sweet spot.  I wonder if this is a factor in what was causing the surprising high number of defect-less reviews in that sample of 300.  Perhaps many of those reviews were for large sections of code.  Or perhaps they’re for reviews that involve only a single line of code.  The study doesn’t go into this.

What the study does go into, is a general guideline for limiting the time that code reviews take.  Their study noted a stark dropoff in review effectiveness after about an hour.  Totally understandable – I think an hour reviewing someone else’s code would probably be my limit before I started getting distracted.

The study then goes on to suggest that the “slower is better” approach to reviewing code is the right idea:

Reviewers slower than 400 lines per hour were above average in their ability to uncover defects. But when faster than 450 lines/hour the defect density is below average in 87% of the cases.

So already there are some guidelines: try to review something around 200 LOC, take your time, but don’t go over an hour.  This is useful information.

The study then goes into a test of a slight modification of how reviews are performed: before submitting code for review, the author should annotate the code, describing how the changes are structured, why they were coded the way they were coded, etc.  This has a dual-benefit:  it gives reviewers some clues at how to look at the code (while, hopefully, maintaining the distance they need to do a good job), and it also has the added benefit of getting the author to go over their code again to weed out obvious defects.

So, some reviews were carried out in this fashion.  Here’s what they found:

First, for all reviews with at least one author preparation comment, defects density is never over 30; in fact the most common case is for there to be no defects at all! Second, reviews without author preparation comments are all over the map [in terms of defect density] whereas author-prepared reviews do not share that variability.

The study gives two possible conclusions for these results:

  1. Authors gave their code such a thorough look while annotating them, that most defects were eliminated right off the bat.  I’m…skeptical of this conclusion.
  2. Since authors were explaining, or defending their changes, this sabotaged the reviewers ability to do their job effectively.

I find myself believing the second conclusion more, simply from experience:  if somebody is guiding me through things, suddenly I’m in the passenger seat, and I’m less inclined to disagree with a change if their explanation or defense sounds solid.

However, Smart Bear disagrees:

A survey of the reviews in question show the author is being conscientious,  careful, and helpful, and not misleading the reviewer. Often the reviewer will respond or ask a question or open a conversation on
another line of code, demonstrating that he was not dulled by the author’s annotations.

…

…we believe that requiring preparation will cause anyone to be more careful, rethink their logic, and write better code overall.

I’d like to see their data on this.  In particular, I’d like to see how often reviewers detected defects in lines of code that the author had annotated.  Unfortunately, this data is not provided in the study.

In the last few pages, the study notes that while review size has a detrimental impact on defect density (the number of defects reviewers found per kLOC), there seemed to be a fixed rate on the number of defects found per hour.  While this seems at odds with the original discovery that smaller reviews are more effective, they note:

Although the smaller reviews afforded a few especially high rates, 94% of all reviews had a defect rate under 20 defects per hour regardless of review size.

…

…the take-home point from Figure 22 is that defect rate is constant across all the reviews regardless of external factors.

So, assume that a reviewer has a steady defect detection rate, but that this rate drops off after about an hour.  Given a small section of code, of course the number of defects detected will be high.  And given a large chunk of code, of course the defects will be more spread out.

It’s the steady defect detection rate that bothers me – you would imagine that the detection rate would depend on the quality of the code and also on the experience of the reviewer.  But I guess, according to this study,  it doesn’t.

And so, the study goes into its conclusions.  I can’t really do much better summarizing the first conclusions for you than they did, so I’ll just regurgitate:

  • LOC under review should be under 200, not to exceed 400. Anything larger overwhelms reviewers and defects are not uncovered.
  • Inspection rates less than 300 LOC/hour result in best defect detection. Rates under 500 are still good; expect to miss significant percentage of defects if faster than that.
  • Authors who prepare the review with annotations and
  • explanations have far fewer defects than those that do not.  We presume the cause to be that authors are forced to self-review the code.
  • Total review time should be less than 60 minutes, not ex- ceed 90. Defect detection rates plummet after that time.
  • Expect defect rates around 15 per hour. Can be higher only with less than 175 LOC under review.
  • Left to their own devices, reviewers’ inspection rate will vary widely, even with similar authors, reviewers, files, and size of the review.

Given these factors, the single best piece of advice we can give is to review between 100 and 300 lines of code at a time and spend 30-60 minutes to review it.  Smaller changes can take less time, but always spend at least 5 minutes, even on a single line of code.

The study then goes into the differences in effectiveness between heavy-duty Fagan-esque code reviews, and the lightweight style of code review that took place at Cisco.  While some of their results from their study exactly match results from studies on heavyweight code reviews (time to spend on a review, when effectiveness drops off), there were some stark differences too.

For example, in the lightweight study, defect detection rate using Smart Bear was 7 times faster than the average rate found across four studies of traditional code review methods.  Sounds like we’re getting into that sales-pitch part…

The study then admits that there was no experiment control – reviews using heavyweight techniques weren’t carried out in parallel with the Code Collaborator study, so comparisons of their effectiveness on the MeetingPlace software have little-to-no data to work with.

In the end, their conclusion is that lightweight code review is just as effective as the traditional methods, while being remarkably faster to boot.  I’d like to see more evidence to back up the comparison on effectiveness, but faster seems more than plausable (Fagan inspections involve very lengthy meetings, so I’ve read).

Smart Bear agrees with my last point on effectiveness comparison, and notes that future study should be conducted where the same set of code is analyzed using both heavy and lightweight methods.

They finish it off with an invitation to software development shops to contact Smart Bear if they’d like to be involved in such a study.

So that’s the gist of it.

Taking a peek at Jason Cohen, Smart Bear, and Code Collaborator

Check this out.

Hang on, hang on, let me back up.

Jason Cohen.  Is that name familiar?  If it isn’t, this is the guy who founded Smart Bear Software.  Smart Bear Software has a piece of software called Code Collaborator, which is a “web-based tool that simplifies and expedites peer code reviews.”  Here’s the sales pitch.

The reason I’m posting all of this is because of what I’m looking for – papers concerning code review, and the relationship (or lack thereof) between code review techniques and computer science education.

Which all traces back to that first link I posted – a series of whitepapers and articles on Code Collaborator, and code reviews in general.  This is good stuff.  Sure, it’s not really oriented around computer science education, but these people seem to know what they’re talking about.

There’s even a free book, which details their massive code review study, which is, apparently, the largest-ever case study of its kind.

I’ve ordered the free book, just for kicks.  In the mean time, I’m going to glance over their Cisco study.
